Unlike conventional alarms that cannot distinguish between objects and people, the SD-H76 uses AI-powered video analysis to accurately detect only the human body. It simultaneously alerts both operators and pedestrians — preventing heavy equipment accidents without false alarms.
Inquire About This SolutionThe AI video analysis system distinguishes people from materials, equipment, and structures on-site, detecting only the human body with precision. It responds only to genuine hazards — with no stress from constant false alarms.
Distinguishes people from objects to detect only the human body with precision.
See the wired system that simultaneously alerts operators and pedestrians to prevent heavy equipment accidents.
Unable to distinguish between objects and people, causing constant false alarms
AI video analysis detects only the human body, alerting only to genuine hazards
Monitors the entire worksite with an expandable 2–4 channel AHD camera system. AI selectively detects only people and simultaneously alerts both operators and pedestrians.
A 720p high-definition touchscreen delivers clear footage even at night.
Top-level dust and waterproofing withstands high-pressure water jets — reliable performance in harsh environments.
Compatible with a wide range of heavy equipment power sources. The monitor supplies power directly to the cameras and alarm unit.
Stores up to 10 days of operating footage, providing clear evidence in the event of an incident.
A flexible system that allows the danger zone to be configured in 4 steps to suit site conditions.
High-brightness LED with a 180° viewing angle and a 2.4W speaker deliver unmistakable warnings to both operators and pedestrians.
Industrial-grade design maintains stable operation even in extreme temperature conditions.
A wired system optimized for company-owned heavy equipment in long-term operation. Powered directly by the equipment — no charging required — and scalable with 2–4 channel expansion to match any site size.
Yellow border highlight and warning light flash on the 7-inch HD monitor. Voice alarm inside the cab for immediate awareness
120dB high-output speaker broadcasts a voice warning to pedestrians in the danger zone. High-brightness LED flashes simultaneously
10 days of operating footage automatically saved to a 128GB SD card. Clear evidence secured in the event of an incident
Compatible with all heavy equipment — including excavators, forklifts, and dump trucks.
Reliable long-term operation that actively prevents accidents on the job site.
| Product Name | Wired Human Detection Pinch Alarm System |
|---|---|
| Detection Technology | AI-Based Video Analytics (Human-Only Detection) |
| Detection Range | 1–12 m (4-Level Adjustable Settings) |
| Installation Type | Wired Installation (Direct Connection to Heavy Equipment Power) |
| Power Supply | DC 12V–36V / Power Consumption: 12W (Standby), 24W (Alarm) |
| Channel Expansion | 2 Channels (Standard) / Expandable up to 4 Channels |
| Video Storage | 128GB Samsung SD Card (Up to 10 Days of Operational Recording) |
| Operating Temperature | Monitor: -20℃ to 70℃ / Camera: -30℃ to 80℃ |
| Ingress Protection | Camera: IP69K / Alarm Unit: IP67 / Monitor Dust Resistance: ISO 16750-3 |
| Alarm Method | Simultaneous Dual Warning for Operator and Pedestrian (Visual + Audible) |
| Applicable Equipment | Excavators, Forklifts, Bulldozers, Dump Trucks, and All Industrial Heavy Machinery |
